9| Dimensions and connections
1) = No connection available as standard.
Available on request (Connection M22 x 1,5)
SV
DV Suction line
Discharge line see technical data, Chapter 8
A Connection suction side, not lockable
1/8" NPTF
A1 Connection suction side, lockable
7/16" UNF
B Connection discharge side, not lockable
1/8" NPTF
B1 Connection discharge side, lockable
7/16" UNF
C Connection oil pressure safety switch OIL
1/8" NPTF
D Connection oil pressure safety switch LP
1/8" NPTF
E Connection oil pressure gauge
1/8" NPTF
F Oil drain
1/4" NPTF
G Opt. connection for oil sump heater
1)
H Oil charge plug
1/4" NPTF
K Sight glass 2 x 1 1/8"- 18 UNEF
L Connection thermal protection thermostat
1/8" NPTF
M Oil filter M22 x 1.5
SV1 Opt. connection for suction line valve - -
