Freerider FR168-3A2/Companion - Manual (Page 36)

36
C O M P A N I O N S P A R E P A R T S C O M P A N I O N S P A R E P A R T S
Your Companion is an electro-mechanical machine.
Some of its consumable components will need replacing due
to normal wear and tear.
The following list of components can be purchased from
your local Freerider Agent from whom you purchased your
Scooter. Quoting model code FR168-3A2 Companion.
DESCRIPTION PART No.
Top Control Console Assembly AA01-0401-B1
Handlebar Rubber Grip PP02-0201
Charger Socket Assembly PAE1-0901-1
Charger Plug NEUTRIK3FX
Front Basket PM90-0400
Battery Bag PP90-0501
Anti-Tipping Wheel PP07-0102
Bearing for Steering Handlebar PM08-0900
Drive Transaxle F-99-S PM11-0216-S
Motor PM11-0305-SY27
Motor Brake PM11-0106
Motor Carbon Brush PM11-0403
Front Wheel Assembly AC12-0300
Front Axle PV00-1202
Front Wheel Bearing (6202ZZ) PM00-0303
Front Tyre (Solid)(200x50K-301) PP92-0201-GK
Rear Tyre 2.80/2.50 PP92-0200-GC
Rear Tube 2.80/2.50 PP93-0200-C
Self Lock Nut Front/Rear Wheel M12 PU00-1202
Floor Mat PP04-0513
Arm Rest Pad PP14-0102
Arm Tighten Knob PP00-0200
Delta Control Kit PA01-A100
Charger Circuit Fuse (3amp) PKE1-1002-1
Battery Cable PK90-0300
Off Board Charging Cable PK90-0401
Power Key (ignition) PM90-0900
Power Key Switch PM01-0100
Horn Button PKE1-0103
Horn PKE1-0605
Battery Meter PKE1-0700
Battery 18 A/H Sealed Lead/Acid PK90-0207-GS
Top Control Board (P.C.B.) PAE1-0301-B1
Controller (Dynamic DS72K-Rhino) PKE2-0100
Potentiometer 5k Assembly PAE1-0200
Potentiometer Spring PM02-0200
Variable Resistor 20k (min-max speed) PAE1-0100
Black Knob (min-max speed) PP01-0500
Circuit Breaker (35amp) PKE2-0403
Warning: Radio wave sources may affect Scooter control.
Your powered Scooter is designed to operate in appropriate
environments, however radio wave sources such as radio or
TV broadcasting stations, amateur (Ham) radio transmitters,
two-way radios and cellular portable telephones can affect
powered motorised Scooters.
The following warnings listed below should reduce the
chance of unintended brake release or uncontrolled powered
Scooter movement.
1. Do not turn on hand held personal communication
devices such as citizen ban (CB) radios and cellular
‘phones, while your Freerider Scooter is turned on.
2. Be aware of nearby transmitters such as radio or TV
stations, and try to avoid coming into close contact with
them.
3. If unintended movement or brake release should occur,
turn your Freerider OFF as quickly as it is safe to do so.
4. Be aware that adding accessories or components or
modifying your Freerider Scooter may make it more
susceptible to interference from radio wave sources.
Note: There is no easy way to evaluate their effect on
the overall immunity of your powered Scooter.
5. Report all incidents of unintended movement or brake
release to your Freerider supplier, noting if there is a radio
wave source nearby. He will then be able to diagnose your
Scooter to eliminate any possible Scooter component
failure. Please note a charge may be made for this service.
Your Scooter has been tested to the following standards with
reference to EN12184. Emissions EN50022(B), Immunity
IEC1000-4-3, E.S.D. IEC801-2
Note: All figures, speeds, measurements and capacities
shown in this manual are approximate and do not constitute
specifications. Our policy is one of continual improvement.
We reserve the right to alter, without notice, any weights,
measurements or other technical data shown in this manual.
If you require specific accurate data, please contact your
Freerider authorised dealer.
Enjoy your Companion
A D V I S O R Y S A F E T Y N O T I C E A D V I S O R Y S A F E T Y N O T I C E
