Setting parameters in the CV-Gate controller mode
To select the CV Gate controller mode, select CV out in the
Audio Out menu. This mode allows to control CV Gate analogue
synthesizers.
Scale the Ribbon
In this mode, the Ribbon sends from 0 to 5V. Range is from 0
to 5V would be about 5 octaves. It is possible to set less
octaves with an attenuator module.
Waveform
When selecting CV is gate, the pressure is disactivated. A Gate
will be send each time the Ribbon is pressed.
Pad destination
CV2 can be controlled by the pressure of the Ribbon or by
the tactile pad
 Ribbon direction
The Ribbon direction can be inversed with its maximu value on
the LED side or with its minimum value on the LED side.
This feature allows to hold the Ribbon with the tactile pad on the
right or on the left. It’s also very useful for left handed players.
