29
230 V
L1 N(L
2
) PE
SECTION OF THE SUPPLY CABLES - TYPE “H05V2V2-F”
resistant to temperatures of 90°C
230 VAC 50 Hz 3 x 0,75 mm 2
✓
The electrical cable must be connected to the terminal board following the diagram
of Fig. 24.
The appliance must be earthed.
The manufacturer declines all responsibility for any problem caused by
failure to observe this rule.
Figure 24
