10
PAN DIAMETER
BURNER MINIMUM MAXIMUM
Auxiliary 12 cm 14 cm
Semirapd 16 cm 24 cm (1)
Rapid 24 cm 26 cm
Triple-ring 26 cm 28 cm
Woks (2) max 36 cm
do not use pans with concave or convex bases
(1) front right burner, maximum diameter 22 cm.
(2) Models with triple-ring burner and with wok pan adapter supplied: wok pans have to
be used only with the special grille fitted (see correct use of triple-ring burner).
CHOICE OF BURNER
The symbols printed on the panel by the side of the knob indicate which burner you
are controlling.
Choose a suitable burner depending on the cookware diameter and capacity.
The pan diameter should be suitable for the burner power to make the most of the
burner's high efficiency and not waste fuel.
A small pan does not boil more quickly on a large burner (fig. 5).
Attention: During use the hob becomes very hot under the cooking zones.
Keep children away.
Figure 5
