Vermont Castings UVS27 Vent-Free Gas Heater
20005004
Optional Accessories Available
Fan Kits
FK28 Fan Assembly
The FK28 fan kit helps distribute heated air from within
the firebox out into the room. The fan is controlled by a
snapstat that turns power on and off as the firebox
temperature rises above and falls below a preset
temperature. A rheostat provides for variable fan
speeds.
Specifications
115 Volt / 60Hz / .75 Amps
Maintenance
The fan itself does not require regular maintenance,
however periodic cleaning of the fan and the surround-
ing area is required.
Installation
Refer to Assembly Section, Page 10 for installation
instructions.
Glass / Catalyst Kit UVGODCFK
The glass panel replaces the standard screen. The
catalytic combustor installs easily into the upper mani-
fold above the firebox.
Remote Controls
The remote control allows you to turn the heater on or
off from anywhere in the room. Remote controls are
available for the UVS27R only. Refer to Figure 17,
Page 12 for wiring diagram.
Model Function/s Controlled
MRC1 ON/OFF
MRC2 ON/OFF and Temperature
MRC3 ON/OFF and Temperature control
with a digital display and a pro
grammable 24 hour clock
IMT Wall mounted thermostat control
Warming Shelf
Warming shelves add versatility to your stove. The
warming shelf can be used to keep foods warm at
mealtime.
Model
Pinnacle Stardance
Shell Shell Color
2702 2702 Classic Black
n/a 2704 Red
n/a 2706 Green
n/a 2711 Moonlight Blue
2764 2764 Sand
2765 2765 Midnight
The shelf installation is done in three stages. First you
attach the shelf loosely to the stove, leaving the screws
loose enough to allow final adjustments. Then, you
position the shelf and adjust the brackets so the shelf
fits correctly. Finally, you tighten the screws.
Refer to the instructions included with each warming
shelf for complete installation procedures.
