23
Vermont Castings UVS27 Vent-Free Gas Heater
20005004
UVS27R, UVS27M Vent Free Gas Heaters
Models 3030, 3031, 3032, 3033 (continued)
Ref. Description UVS27
2a. Manifold Assy. - UVS27R 20003739
2b. Manifold Assy. - UVS27M 20004935
3. Damper Steel Handle/Screw (Stardance Operable Door Only) 5004265
4. Handle Package, Ceramic w/Screw (Stardance Operable Door Only) 0004342
5. Trim ON/OFF Switch 53606
6. Screen UVS27 20005009
7. Glass Frame Assembly - SDV30 30000127
8. Glass w/Gasket (Comes with UVGDCFK) 30000523
9a. Valve NG Honeywell - VS84212003 10000235
9b. Valve LP Honeywell - VS84212011 10000242
9c. Valve MN Eurosit 0.630.564 20001354
9d. Valve MP Eurosit 0.630.563 20001355
10a. Oxygenerator, NG OP #8204 55464
10b. Oxygenerator, LP OP #8404 55465
10c. Oxygenerator, NG OP #8202 20004435
10d. Pilot ODS TP OP #8402 20001357
11. Front, Stardance OP DR (Stardance Only) Refer to Enamel Parts Chart Page 24
12. Door, Left - Stardance Refer to Enamel Parts Chart Page 24
13. Door, Right - Stardance Refer to Enamel Parts Chart Page 24
14a. Burner Housing Assy. - JUV NG 20003130
14b. Burner Housing Assy. - LP 20004995
15. Bracket, Rear Log - JUV 20003274
16a. Orifice Hood #69 (.0292”) - Front - LP 30000513
16b. Orifice Hood #54 (.055”) - Front - NG 20000130
16c. Orifice Hood #54 (.055”) - Rear - LP 20000130
16d. Orifice Hood #44 (.086”) - Rear - NG 30000334
17. Ignitor Piezo - Honeywell #396079 20000062
18. Gasket, Base Pan Inner 20002566
19. Bracket Support Right Log 20004920
20. Bracket Support Left Log 20005022
21. Grate Decorative Burner 20003022
22. Grille, UV30 30000393
23. Mesh, Grille - UV30 30000508
24. Top, Stardance UV/PDV Refer to Enamel Parts Chart Page 24
25. Front, Stardance Refer to Enamel Parts Chart Page 24
26. Front, HM-VC Refer to Enamel Parts Chart Page 24
27. Door, Control - FS/HM Refer to Enamel Parts Chart Page 24
28. Cover, Valve w/Piezo 51851
29. Catalyst, RUV (not shown) (Comes with UVGDCFK) 30000506
