12
IMPORTANT: If dumping by electric lift, stop immediately
if actuator clutch slippage occurs. Lower cargo box
completely and remove excess load by hand before
dumping.
• Reconnect the tailgate to the cargo box. Do not
drive the vehicle with cargo box in the raised
position.
Loading the Cargo Box
WARNING: The utility vehicle may become
unstable if the cargo box is loaded
incorrectly. Avoid loose and shifting loads or
uneven loading of material.
• Verify cargo box is latched before loading.
• Securely anchor all loads in cargo box and do not
load beyond maximum capacity.
• The maximum box capacity is 800 lbs (362.9 kg).
• When loading objects into vehicle, be sure load is
securely anchored and evenly distributed in cargo
box.
• Do not load above height of cargo box front panel.
Load could shift forward striking driver or
passenger or cause driver to loose control of
vehicle.
• Avoid loads which exceed physical dimensions of
cargo box.
• Avoid concentrated loads at rear or side of cargo
box. Be sure load is distributed evenly.
• Reduce load and ground speed when operating
over rough or hilly terrain. DO NOT overload
vehicle. Limit loads to those that can be safely
controlled.
Towing Loads
WARNING: To help prevent personal injury
due to loss of control or tipping, always tow a
load slowly enough to maintain control.
• Do not tow a load that exceeds 900 lbs.(454.5 kg)
rolling weight (i.e. trailer plus cargo) and never
exceed 100lbs (45.5kg) tongue weight.
• Go slow when towing a heavy load. Allow for
increased braking distance. Tow load at a speed
slow enough to maintain control.
• Do not tow on steep slopes.
• Be particularly cautious when towing down even a
gradual slope or turning. The extra weight tends to
push the tow vehicle and may cause you to lose
control (braking and steering ability are reduced;
towed equipment may jack-knife).
IMPORTANT: Extreme angles such as high railroad
crossings can place high bending loads on hitch
connection. If traversing terrain where these conditions
exist, use of a ball or pintle type hitch is recommended.
• Always use approved hitch and hitch point provided
for the utility vehicle. Do not modify the hitch in any
way.
Transporting Vehicle
IMPORTANT: Never tow the vehicle. Transaxle damage
will occur if vehicle is towed. Haul the vehicle on a
heavy-duty trailer or on a full-size truck.
• Once the utility vehicle is loaded onto the trailer or
truck, leave transaxle gearshift lever in forward or
reverse.
• Apply parking brake and turn fuel shut-off valve to
OFF position during transport.
• Fasten vehicle to trailer or truck with straps, chains,
or cables.
SECTION 4: SERVICING YOUR UTILITY VEHICLE
Lubrication
Front Axle Lubrication
• Lubricate one grease fitting on each axle with 2 or 3
shots of grease every 50 hours.
Engine
Read the engine operator’s manual for any service or
maintenance information pertaining to the engine.
Filling Fuel Tank
• Stop the vehicle on a level surface and apply
parking brake.
• Turn the ignition key to the STOP position and
remove the key.
• Allow engine to cool several minutes before you
add fuel.
• Clean area around fuel cap and remove cap.
See Figure 13.
• Fill tank with fresh, stabilized fuel only to bottom of
filler neck.
• Install fuel tank cap.
