DVR User Manual
5
Name
Description
REC
When recording, the light is blue
Net
When access to network , the light is blue
Power
Power indicator, when connection , the light is blue
Fn
Switch the output between VGA and BNC
The other kind of the front panel:
Name
Description
Power indicator
Power Indicator, when connected, the light is blue.
HDD indicator
The light turns blue when reading/writing HDD.
Net indicator
The light turns blue when it is able to access the network.
Backup indicator
The light turns blue when backing up files and data.
Play indicator
The light turns blue when playing video.
REC indicator
The light turns blue when recording
Record button
Record manually
Play button
Enter play interface
REW button
Rewind key
FF button
Fast forward
MENU/+ button
1. Enter menu in live 2. Increase the value in setup
BACKUP/- button
1. Decrease the value in setup 2. Enter backup mode in live
STOP/ESC button
1. Quit play mode 2. Exit the current interface or status
Direction button/
Multi-screen
Change direction to select items
Change screen display mode like1/4/9/16 channel
Enter button
Confirm selection
IR
For remote controller
