COP-USA DVRC264-16ME-A - Manual (Page 116)

8/16-CH DVR Quick Start Guide
7
Select day and then click „Add‟ button to setup the start time and end time.
Then select other days and click „Copy‟ button to save the setting to other days.
Finally, click „OK‟ button to save week schedule.
Step 4: Select other channels and set timeline for them or select „Apply
Settings To All Channel and click “Copy” button to set the same settings for all
channels.
7.3 Motion Based Recording
Motion detection based recording: when there is a motion event detected, the
camera will be triggered to record.
To Setup Motion Based Recording:
Step 1: Enter into MenuSetupScheduleMotion tab. The setup steps for
schedule for motion based recording are similar to normal schedule setup. You
can refer to 7.3 Schedule Recording for details.
Step 2: Enter into MenuSetupAlarmMotionMotion tab as shown
below.
Step3: Enable motion alarm (Please specify to channel) and click „Apply‟ to
save settings.
Step4: Click „Setting‟ button under the Area to set Sensitivity and Detection
area. Left click the grid and drag to delete the area. Drag again to add area.
You can drag slide bar to set the sensitivity value (1-8). The higher the value is
the more sensitive it is to motion. Since the sensitivity is influenced by color
and time (day or night), you can adjust its value according to the practical
conditions. Click
icon to set the whole area as detection area. Click
icon to clear the set detection area. Click icon to test the sensitivity as per
the local conditions. Once motion is sensed, it displays a figure icon. Click
icon to save the setting. Click icon, exit current interface.
