COP-USA PKG-DVR04 User Manual
Page 64
64
The functions of buttons show as follows:
Table 1-1
Function keys
Definition
Function specification
Play
When the program connects with device, play video
Capture
Capture the current screen(the default save path: the default pictures
directory of mobile)
Settings
Set some information of the device, such as IP address, dynamic domain
name, port, username, password and device alias information.
About
Some device information of the software
Previous group
It can show the previous channels group.
Next group
It can show the next channels group.
Select channel
Choose one video channel of the device. And cooperate with "next
group" can switch the 8 or 16 channels.
PTZ control
PTZ direction control including up, down, left and right.
Zoom
Zoom in/out control of PTZ.
Focal length
Focal length adjustment of PTZ.
Aperture
Aperture control of PTZ.
4）If it is first running or need to change the parameters, please click the
and enter the
