Operation Manual for Intelligent Speed Dome Camera
2
II. Description of Functions
The intelligent dome camera is a hi-tech CCTV product which incorporates high-clarity
color camera, panoramic speed-variable PAN/TILT, multifunctional decoder, CPU processor,
memory chip into a whole. It can largely reduce connection and installation processes of
components in the system, rise up reliability of the system and facilitate installation and
maintenance. Therefore it has advantages of beautiful appearance, compact structure and easy
operation.
1. Integrated Multi-Protocol Decoder
a. With integrated decoder and multi-protocol, it can integrate 16 kinds of
communication protocols in maximum. As its baud rate of communication can be
adjusted, it is compatible with many normal systems by easy setup inside the dome
camera, so it has stronger versatility.
b. RS485 serial control: addresses of camera 1-1023.
2. Integrated speed-variable PAN/TILT
a.
Turning
360
º horizontally and continuously with unlimited positions and an
adjustable speed from 0.2 -- 80rad/s ; turning 0 - 90
º vertically with a speed up to 12 rad/s.
b. Running stably at low speed with super lower noise. Pictures have no shaking.
c. the location precision up to
±0.2°.
3. High Intelligent Degree
a. As much as 64 preset positions can be preset with powerless memory;
b. The camera can scan horizontally between two points and scan speed can be modified.
The positions of linear scan are optional and the dome camera can scan the range
larger or smaller than 180° between any two points with adjustable speed;
c. Six sets of programmable patrol with 16 position each set. The running speed and the
detention time are adjustable respectively;
d. The Integrated Multi-Protocol. Multiple communication protocols are integrated
inside the dome camera with selectable baud rate from 2400 bps to 9200 bps.
4. Functions of the Camera
a. Description of the Focus Control Mode: the user can adjust the focus of the camera
manually.
b. Description of Backlight Compensation: when the object to be shot is dark and
looks dim, the user can open the backlight compensation according to actual need.
c. Description of White Balance: when the image has color distort on the screen, the
user can set different modes by orders.
d. Description of ZOOM Control: user can “pull near” or “push far” the lens according
to actual conditions.
e. Description of Electronic Shutter: it is fixed on 1/50 sec after initialization when the
camera is switched on.
f. AE Mode: setup of Manual/Automatic.
g.
Minimum illumination : it is used only when the external brightness is extremely low.
Normally the camera works on the automatic state. In case the external brightness is
lower than 1Lux, the camera can be switch to the
Minimum illumination state
automatically You can also set the Minimum illumination state manually.
LENS Minimum illumination
16x f =3.9 to 63mm (F1.6 DC Iris) 1 Lux (F1.6)
18x f =4.1 to 73.8 mm (F1.4 to F3.0) 1 Lux (common) / 0.01 Lux
（B & W）
22x f =4 to 88 mm (F1.6 to F3.8) 0.2 Lux
（F1.6 1/3s）
23x f =3.6 to 82.8 mm (F1.6 to F3.7) 0.01 Lux
（B & W）
26x f =3.5 to 91 mm (F1.6 to F3.8) 0.01 Lux
（B & W）
