4. FUNCTION
MIRROR
ON This Option allows you to mirror the image horizontally
OFF Disables the feature
SHARPNESS (0~30)
Adjust the Image Sharpness decreasing or Increasing the Values
LSC (Lens Shading compensation) which compensates brightness of
four lens’ corners. So that the LSC function activates to get a clear
image effectively. Is recommended to leave it OFF.
ON ‐ SET LEVEL (0~30)
5. MOTION
AREA SEL:
Adjust each square to cover movement anywhere on the screen area.There are 4 area
selections that you can choose from. You will notice that each area will be displayed
with a pink box, the area within pink box is where the motion will be activated.
MASK MODE (ON/OFF)
TOP (000~122)
BOTTOM(000~122)
LEFT(000~122)
RIGHT(000~122)
RETURN(000~122)
MOTION DET. (ON/OFF)
This Function allows to identify the area where the motion is detected
AREA SELECT. 1~4
This function enables up to 4 motion areas.
SENSITI. (001~30)
The higher
the setting, the more movement it will catch.
DISPLAY ( OFF/ICON/TRACE )
If set to Icon, this icon will pop‐up when detects motion
If set to Trace, the masking area will be shown on the screen in a red transparent
background .
HOLD TIME
For example if you have the setting at 4, the camera will not
signal motion until 4 seconds later as long as that object is still moving within the
selected mask area. If you want instant motion detection notification, then please
set this at 0.
