9. 3D-DNR (3D Noise Reduction)
10. EFFECTS
The background noise in the low light level decreases
automatically as the level of gain changes.
- DNR LEVEL
Adjust the noise reduction level.
- DESTINATION
Adjust the 3DNR gain.
- GLOBAL MOVEMENT
Control ghost phenomenon
- D-ZOOM : You can use a digital zoom.
• ZOOM : x1 ~ x8.30
• DZOOM PAN : -100 ~ 100
• DZOOM TILT : -100 ~ 100
- IMAGE FREEZE : You can view still or live image.
- D-EFFECT
• V-FLIP : You can flip the picture vertically on the screen.
• MIRROR : You can flip the picture horizontally on the screen.
• ROTATE : You can flip the picture rotatively on the screen.
- CONTRAST : 0 ~ 100
- SHARPNESS : 0 ~ 100
- COLOR ADJUST
• COLOR : ON/OFF
• COLOR LEVEL : 0 ~ 200
• COLOR HUE : -180 ~ 180
• RED GAIN : -100 ~ 100
• BLUE GAIN : -100 ~ 100
- INITIAL SET : Initialize all settings of EFFECTS menu.
( TARGET CROSS and BAD PIXEL modes are not initialized)
- PREVIOUS
11. SPECIAL MENU
ITS MODE (OFF)
MOTION (Motion Detection: MD)
This product has a feature that allows you to observe
movement of objects in 8 different areas on the screen, and the
words 'MOTION' appear on the screen when movement is
detected. You can monitor activity more effi ciently.
- ZONE NUMBER : You can select up to 8 MD areas.
- ZONE STATE : Determines whether to use the MD area
selected in ZONE NUMBER.
- WIDTH : Determines the coordinate of the horizontal size.
- HEIGHT : Determines the coordinate of the vertical size.
- MOVE X : Determines the coordinate of the horizontal axis.
- MOVE Y : Determines the coordinate of the vertical axis.
- SENSITIVITY : Determines the coordinate of the sensitivity.
- INITIAL SET : Initialize all setting of MOTION DET menu.
- SAVE : Select this to save the MOTION menu setting and
return to the SPECIAL menu.
PRIVACY (Privacy Masking)
This function helps you mask an area you want to hide on the
screen.
- MASK NUMBER : You can select up to 8 PRIVACY areas.
- MAKS STATE : Determines whether to use the selected in
AREA SELECT.
- SENSITIVITY : Determines area color. You can select GRAY,
WHITE, RED, GREEN, BLUE, YELLOW,
BLACK.
- WIDTH : Determines the coordinate of the horizontal size.
- HEIGHT : Determines the coordinate of the vertical size.
- MOVE X : Determines the coordinate of the horizontal axis.
- MOVE Y : Determines the coordinate of the vertical axis.
- INITIAL SET : Initialize all setting of PRIVACY menu.
- SAVE : Select this to save the PRIVACY menu setting and
return to the SPECIAL menu.
1. CAM NAME
2. LENS
3. EXPOSURE
4. DAY/NIGHT
5. WDR/BLC/ECLPS
6.WHITE BAL
>7. 3D-DNR
8.EFFECTS
9.SPECIAL
10.EXIT
OFF
MANUAL
AUTO
WDR
ATW
ON
RET
ITS MODE
MOTION DET
PRIVACY MASK
LANGUAGE
STABILIZER
L/L SYNC
MONITOR TYPE
FACTORY RESET
COMM SET
PREVIOUS OFF
OFF
OFF
ENGLISH
OFF
INT
CRT
ITS MODE
MOTION DET
PRIVACY MASK
LANGUAGE
STABILIZER
L/L SYNC
MONITOR TYPE
FACTORY RESET
COMM SET
PREVIOUS OFF
OFF
OFF
ENGLISH
OFF
INT
CRT
1. CAM NAME
2. LENS
3. EXPOSURE
4. DAY/NIGHT
5. WDR/BLC/ECLPS
6.WHITE BAL
7. 3D-DNR
>8.EFFECTS
9.SPECIAL
10.EXIT
OFF
MANUAL
AUTO
WDR
ATW
ON
RET
<3D-DNR MENU>
DNR LEVEL
DESTINATION
GLOBAL MOVEMENT
PREVIOUS 24 ......|.........
47 ...........|....
OFF
DZOOM MODE
IMAGE FREEZE
D-EFFECT
CONTRAST
SHARPNESS
COLOR ADJUST
INITIAL SET
PREVIOUS OFF
OFF
50......|.......
50......|.......
