128 TalkSwitch User Manual
SS S Syyyysssstttteee em m m m
Music input Phono jack (mono)
P.A. output Phono jack (mono)
Power source AC wall adapter
120VAC/16VAC 2.0A
Power switch Push Button
DTMF detectors 4 / 8* @ -3dBm to -30dBm
Dial tone generators 1
Ring detectors 2 / 4*
Power-failure pass through Extension 4 connects to Line 1
Dimensions (H) 51.6mm x (W) 203.2mm x
(L) 213.4mm
Weight 0.675 kg / 0.930 kg*
Approvals FCC parts 15 and 68
Industry Canada CS-03
EN 60950 - 1992, including:
Amendments 1, 2, 3, 4, 11.
* Applies to TalkSwitch 48 models only.
