23
CANNON CANNON CANNON CANNON CANNON ® CT-500/600 Series II CONSTANT TEMPERATURE BATH
Version 3..3—March, 2012; CANNON CANNON CANNON CANNON CANNON ® Instrument Company
2139 High Tech Road • State College, PA • 16803 • USA
CHAPTER
B
APPENDIX B
—
REPLACEMENT PARTS LIST
Following is a list of parts for the CT-500/600 series instruments. Parts
may be reordered from CANNON
® Instrument Company. Only use
CANNON ® -authorized replacement parts for service.
ALL INSTRUMENTS
PART #
DESCRIPTION
P20.22 THERMOMETER HOLDER
P20.40 IMPELLER STIRRER LOWER CT500 & CT518 & CT524
P22.39 HOLE COVERS & THERM HOLDER SET
P25.2455 FUSE 12A 250V MEDIUM BLOW QTY (2)
P25.3111 FRONT BATH COVER
P25.3180 PROBE ASSY CONTROL
P25.3190 PROBE ASSY OVER-TEMP
P27.2230.1 LAMP RESET SWITCH 12V
P27.3700 SCREWDRIVER TRIMPOT (OVER-TEMP ADJUST)
P27.6121 SUPPORT PAD SPONGE
P50.82 10-TURN DIAL
CT-500 ONLY
PART #
DESCRIPTION
P20.1 PYREX JAR 12 X 12 CT500
P25.4005 MOTOR STIRRER ASSY 115V CT500
P25.4006 MOTOR STIRRER ASSY 230V CT500
P27.5250 PTFE COATED BAFFLE WHITE CT500
CT-518/524
PART #
DESCRIPTION
P20.1A PYREX JAR 12 X 18 (CT-518 ONLY)
P20.1B PYREX JAR 12 X 24 (CT-524 ONLY)
P25.6010 IMPELLER STIRRER UPPER
P25.6027 MOTOR STIRRER ASSY
P25.6028 MOTOR STIRRER ASSY
P25.6006 PTFE COATED BAFFLE WHITE
CT-600 ONLY
PART #
DESCRIPTION
P30.1048 MOTOR STIRRER ASSY 115V
P30.1051 MOTOR STIRRER ASSY 230V
