3 Technical data
12 B-411/E-416 Operation Manual, Version E
3 .2 Technical data overview
Table 3-4: Technical data
Hydrolysis Unit B-411/E-416
Dimensions (W x H x D) 275 x 600 x 570 mm
Weight B-411: 13.5 kg
E-416: 14.5 kg
Power system voltage / frequency 230 V ± 10 % / 50 Hz
120 V ± 10 % / 60 Hz 140 W
100 W
Ambient temperature For indoor use only, altitude up to 2000 m above sea
level, maximum relative humidity 80 % for temperatures
up to 30 °C, 10 - 40 °C
Overvoltage category II
Pollution degree 2
Power consumption 1100 W
3 .3 Materials used
Table 3-5: Materials used
Component Material designation Material code
Glass Borosilicate glass 3.3
Housing Stainless steel 1.4301
Housing cover Plastic PPO + Glass fiber
Insulation plate heating Alkaline earth-silicate fiber
Rubber coupling EPDM
