6 Operation
29 E-812/816 Hot Extraction Operation Manual, Version B
6 .3 Description of the menu functions
6 .3 .1 Starting up the instrument
Make sure, that the instrument is correctly connected to the mains supply and the cooling water. Then
switch on the instrument at the main switch. The main screen appears:
Fig. 6.1: Main screen
6 .3 .2 Instrument settings
To define the instrument settings, press the Menu button. The following screen opens:
Fig. 6.2: Menu
Select instrument settings and press the forward button.
Fig. 6.3: Instrument settings
