4 Description of function
18
E-812/816 Hot Extraction Operation Manual, Version B
4
Description of function
This chapter explains the basic principle of the instrument, shows how it is structured and gives a
functional description of the assemblies.
4 .1
Overview over the instrument
1
2
3
4
5
a Condensers
b Protective shield
c Beakers with sample tubes
d Heating plate
e Operating panel
Fig. 4.1: Overview over the instrument
