3 Technical data
14 E-812/816 Hot Extraction Operation Manual, Version B
Table 3-2: Standard accessories (cont.)
E-812 E-816 Product Order
number
1 1 Plastic funnel 51167
1 1 Hose adapter for cooling media input 49151
1 1 Cooling water hose complete,
G3/4”, G1/2”, L = 1.5 m 37780
1 2
1 1 Solvent hose, Tygon SE 200, 1 m a 49450
1 1 PTFE hose, 500 mm b 25315
1
2
3
4
5
2 2 Knurled screw (for solvent hose) a 43237
2 2 Clamping ring (for solvent hose) a 43238
5 5 Hose clamp, Ø 9.6 mm b 27738
2 2 Hose, silicone, Ø 6/9
L = 1.5 m c 43940
2 2 Condenser connection hose, silicone,
L = 0.35 m, mounted 49161
1 5 Condenser hose, silicone, L = 0.20 m d 49163
2 2 Hose coupling (wide and small) e 43565
1 3 Set of seals, Viton, 2 pieces 49431
2 6 Seal PVDF holder 47610
1 1 Set of seals PTFE 49433
