3 Technical data
12 F-125 Manual, Version B
3 Technical data
This section introduces the reader to the Recirculating Chiller and its specifications. It contains the
technical data, requirements and performance data.
3 .1 Technical data
Technical data
Power consumption (max.)
2850 W
Supply voltage 230 VAC ± 10%
Fuse 16 AT
Output socket (max.) 2 A
Frequency 50/60 Hz
Environmental conditions
- Temperature
- Altitude
- Humidity For indoor use only
5-40 °C
up to 2000 m
Maximum relative humidity 80% for temperatures up to 31 °C decreasing
linearly to 50% relative humidity at 40 °C
Display digital, resolution 0.1 °C
Overvoltage category II
Degree of protection IP20
Pollution degree 2
Instrument dimensions
W x H x D 990 x 580 x 650 mm
Weight 100 kg
Cooling power at 15 °C 2500 W
Refrigerant R134
Temperature range -10 °C ... +25 °C
Hysteresis ±1 °C
Tank volume 9 l
Hose connection 13.5 mm
Pump flowrate 14 l/min
Pump pressure 2.5 bar
3 .2 Materials used
Materials used
Component Material designation Material code Hazardous substances
Stainless steel, powder-coated with
polyester-epoxide Housing 1.4301
–
Polyester Lamina PES –
Glass-fiber-reinforced epoxy resin Circuit board –
Polyvinyl chloride Cable PVC –
R134 Refrigerant 1,1,1,2-tetrafluoro-
ethane Check MSDS
