Glass Oven B-585 8 Replacement parts
Fig. 30: Sublimation accessory complet
Fig. 28: Kugelrohr
Fig. 29: Hose connection assembly with stopcock
36771
37132
37287
37286
37288
36766
37287
37286
37132
37285
02965
complet 37133
8.2 B-585 Kugelrohr configuration replacement
parts
Description Order Code
10 ml ball tube (Ns 14.5/23)
with vapour duct and clips 37118
20ml ball tube (Ns 14.5/23)
with vapour duct and clips
37107
40ml ball tube (Ns 14.5/23)
with vapour duct and clips
37117
Rotation drying flask with vapour duct and
clip 37143
Communication cable B-585/V-5xx 46728
10 Device fuses 3,15 AT 19659
Connection piece 36771
Stopcock 37132
Cooling dish 37152
Set STJ (12 pieces) 37286
Set hose nipples GL14 (4 pieces) 37287
Set vacuum gaskets (5 pieces) 37288
Nozzle cap 36824
Chlambing cone 36770
8.3 Sublimation accessory replacement parts
Complete sublimation accessory 37133
Drying tube 02965
Flange ring 02970
Sublimation insert 36766
Cock 37132
Set flange screw, spring, gasket 37285
Set STJ (12 pieces) 37286
Set hose nipples GL14 (4 pieces) 37287
37118
37286
37286
37286
37117
37107
37143
37286
37101 37102
37104 37106
36479 36478
36480
37073
37073
37073
37125
