6 Operation

22

F-100 / F-105 / F-108 / F-114 Operation Manual, Version E

6 .2 .1

Installing the hoses

!

WARNING

Stumbling or falling due to improper installation of the cables and hoses.
• The length of the cables and hoses should be kept as short as possible
• If possible, avoid installing cables and hoses in aisle areas
• If installation of cables and hoses in aisle areas is unavoidable, use an adequate protective

pad in order to avoid the danger of stumbling and damage

• Connect out flow and return flow connections of the Recirculating Chiller with the condenser of the

rotary evaporator.

NOTE
Only use hoses which can withstand min. -10 °C and 2 bar pressure and secure them with the usual
hose clamps.

• Connect Chiller outlet (OUT) to the second condenser installed on the pump.
• Connect the outlet of the second condenser to the Rotavapor

®

Condenser.

• Connect the outlet of the Rotavapor

®

Condenser to the inlet (IN) of the Recirculating Chiller.

6 .2 .2

Filling the chiller

NOTICE

Risk of instrument damage if wrong cooling medium is used.
• Check to ensure that the cooling medium is suitable for use at the desired cooling tempera-

ture and does not freeze at the working temperature

Fill the cooling liquid in the opening to maximum filling level while the chiller is not connected to
another device. We recommend a mixture of ethylene glycol/water at least 40/60, which does not
freeze until -16 °C.
