3 Technical data

11

F-100 / F-105 / F-108 / F-114 Operation Manual, Version E

3

Technical data

This section introduces the reader to the Recirculating Chiller and its specifications. It contains the
technical data, requirements and performance data.

3 .1

Technical data

Technical data (230 V)

F-100

F-105

F-108

F-114

Power consumption (max.) 850 W

850 W

1350 W

1850 W

Supply voltage

230 VAC ±10 %

230 VAC ±10 %

230 VAC ±10 %

230 VAC ±10 %

Fuse

6.3 AT

6.3 AT

7 AT

8 AT

Frequency

50/60 Hz

50/60 Hz

50/60 Hz

50/60 Hz

Environmental conditions

For indoor use only

- Temperature

5–35 °C

5–35 °C

5–40 °C

5–40 °C

- Altitude

up to 2000 m

- Humidity

Maximum relative humidity 80 % for
temperatures up to 31 °C decreasing
linearly to 50 % relative humidity at 40 °C

Display

No display

digital, resolution
0.1 °C

digital, resolution
0.1 °C

digital, resolution
0.1 °C

Overvoltage category

II

II

II

II

Degree of protection

IP20

IP20

IP20

IP20

Pollution degree

2

2

2

2

Instrument dimensions
W×H×D [mm]

280Ч500Ч420

280Ч500Ч420

400Ч580Ч500

400Ч660Ч500

Weight

28 kg

30 kg

40 kg

42 kg

Cooling power at 15 °C

400 W

500 W

800 W

1400 W

Refrigerant

R134

R134

R134

R134

Temperature range

fix +10 °C

-5 °C ... +25 °C

-10 °C ... +25 °C

-10 °C ... +25 °C

Accuracy

±2 °C

±1 °C

±1 °C

±1 °C

Tank volume

3 L

3 L

4.5 L

6.6 L

Hose connection

8 mm

8 mm

9.5 mm

13.5 mm

Pump flow rate

2.5 L/min

2.5 L/min

3.0 L/min

11.0 L/min

Pump pressure

0.6 bar

0.6 bar

0.6 bar

1.0 bar
