Brookfield Engineering Labs., Inc. Page 28 Manual No. M/05-370-A1205
Conical Probes
TA2/100
60
°
, 30 mm D, Clear Perspex (low mass)
TA2/1000* 60
°
, 30 mm D, Clear Perspex
TA15/100 45
°
, 30 mm D, Clear Perspex (low mass)
TA15/1000* 45
°
, 30 mm D, Clear Perspex
TA16 40
°
, 28 mm D, Clear Perspex
TA17* 30
°
, 25 mm D, Clear Perspex
TA27 20
°
, 12 mm D, Clear Perspex
TA29 15
°
, 8 mm D, Stainless Steel
TA32/100 90
°
, 30 mm D, Clear Perspex (low mass)
TA32/1000 90
°
, 30 mm D, Clear Perspex
Spherical Probes
TA8
6.35 mm D, Stainless Steel
TA18* 12.7 mm D, Stainless Steel
TA28 2 mm D, Stainless Steel
TA31 1 mm D, Stainless Steel
TA33 3 mm D, Stainless Steel
TA38 10 mm D, Stainless Steel
TA43* 25.4 mm D, Nylon
Special Purpose Probes
TA26*
0.33 mm D, 40 mm W, Cutting Wire, Aluminum
TA37 2.36 mm D, 40 mm W, Cutting Wire, Aluminum
TA7* Knife Edge, 60 mm W, Clear Perspex
TA9* Needle, 1.0 mm D, 46 mm L, 10
°
Maximum Taper
TA19 1 cm 2 Kobe Test, 11.3 mm D, 25 mm L Stainless Steel
TA22 18 SWG Bar Frame
TA23 12.7 mm DIA Round End
TA49 25.4 mm DIA Round End
KEY:
D = diameter
L = length
W = width
AOAC = Association of Official Analytical Chemists
*This part contained in Standard Probe Kit TA-P-KIT2
LFRA FIXTURES AND JIGS
TA-ATT Adhesive Tack Tester
TA-AVJ Adjustable Vice Jig
TA-BEC Back Extrusion Cell
TA-JTPB Junior Three Point Bend
TA-JPA Junior Punch Assembly
