Brookfield Engineering Laboratories, Inc. Page 19 Manual No. M/85-150-P700
UL Adapter
Cone/Plate Viscometer
Helipath with T-Bar Spindles
YULA-15 or 15Z 1.22N 1.0 - 2,000 6.4 - 2,000 12.8 - 2,000 51.2 - 2,000
ULA-DIN-Y 1.29N 1.9 - 3,812 12.2 - 5,000 24.4 - 5,000 97.6 - 5,000
UL Shear Rate
Spindle (1/SEC) LVT RVT HAT HBT
Viscosity (cP)
N = RPM
Cone Shear Rate
Spindle (1/SEC) LVTC/P RVTC/P HATC/P HBTC/P
Viscosity (cP)
N = RPM
CP-40 7.5N 0.5 - 1,028 3.3 - 6,540 6.6 - 13,080 26.2 - 52,400
CP-41 2.0N 1.9 - 3,840 12.3 - 24,576 24.6 - 49,152 98.4 - 196,600
CP-42 3.84N 1.0 - 2,000 6.4 - 12,800 12.8 - 25,600 51.2 - 102,400
CP-51 3.84N 8.1 - 16,180 51.2 - 102,400 102.4 - 204,800 409.6 - 819,200
CP-52 2.0N 15.5 - 31,065 98.3 - 196,600 196.6 - 393,200 786.4 - 1,572,800
T-A 156 - 3,120 156 - 62,400
T-B 312 - 6,240 312 - 124,800
T-C 780 - 15,600 780 - 312,000
T-D 1,560 - 31,200 1,560 - 624,000
T-E 3,900 - 78,000 3,900 - 1,560,000
T-F 7,800 - 156,000 7,800 - 3,120,000
T-Bar
Spindle LVF LVT
Viscosity (cP)
T-A 2,000 - 100,000 2,000 - 400,000
T-B 4,000 - 200,000 4,000 - 800,000
T-C 10,000 - 500,000 10,000 - 2,000,000
T-D 20,000 - 1,000,000 20,000 - 4,000,000
T-E 50,000 - 2,500,000 50,000 - 10,000,000
T-F 100,000 - 5,000,000 100,000 - 20,000,000
T-Bar
Spindle RVF RVT
Viscosity (cP)
T-A 4,000 - 800,000 16,000 - 3,200,000
T-B 8,000 - 1,600,000 32,000 - 6,400,000
T-C 20,000 - 4,000,000 80,000 - 16,000,000
T-D 40,000 - 8,000,000 160,000 - 32,000,000
T-E 100,000 - 20,000,000 400,000 - 80,000,000
T-F 200,000 - 40,000,000 800,000 - 160,000,000
T-Bar
Spindle HAT HBT
Viscosity (cP)
