AW900iTR

User’s Manual

PAGE 2

Technical Support (650) 384-0000

www.avalanwireless.com

Revision 03.21.2013

125A Castle Drive

Madison, AL 35758

Sales: (866) 533-6216

Technical Support: (650) 384-0000

Customer Service: (650) 641-3011

Fax: (650) 249-3591

Thank you for your purchase of the AW900iTR Indoor Wireless Ethernet Radio.

TABLE OF CONTENTS
Quick Start Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Operational Summary Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Physical Setup Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Digital Setup Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
LCD Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Radio Status Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Antenna Alignment Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Transmitter to Reciever Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Abbreviation Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

If you have any questions when configuring your AvaLAN system, the best place to get answers is

to visit www.avalanwireless.com. You will also find the latest updates there. If more assistance

is needed, send email to [email protected].

To speak to a live technician, please call technical support at the number below during normal

business hours.

The AW900iTR includes:

(1) AW900iTR radio in extruded aluminum box

(1) AW2-900 2.5dBi omnidirectional antenna

(1) 110 VAC to 12 VDC power adapter

The AW900iTR-PAIR includes:

(2) AW900iTR preconfigured radios in extruded aluminum box

(2) AW2-900 2.5dBi omnidirectional antenna

(2) 110 VAC to 12 VDC power adapter
