BASIC HOOK UP

To control a typical analogue synth, the most basic and common way to set up is as follows;

Oberkorn Output

Synth Input

Pitch:

VOLTAGE OUT A

CV (pitch) / Key CV

Gate:

GATE OUT X

Gate / Trig / V-Trig

Cutoff:

VOLTAGE OUT B

VCF

Note: different synth’s will label their inputs differently.

That’s a basic set-up. If you are new to analogue synth’s you may just want to stick with that
for starters, just to get used to using the set-up. But more advanced users really should do a
little more than the above! I’ll give more advanced examples later.
