Instant Replay Owner’s Manual

Record Overwrite - OFF, ON
Record Time Limit - NONE, 60 MIN, 30 MIN, 5 MIN (On 16 and 24 hour units this is
set to 60 min during factory set-up to speed the Record process.)
Record/Erase Lockout - OFF, ON
Recording Format – AC-2, 48K Linear, 44.1K Linear
Sample Rate Converter – Enabled, Disabled

Operations

Change Cut Name - Changes name of currently selected Cut.
Erase - Erases currently selected Cut.
Move - Move currently selected Cut to any unused Index number.
Adjust Output Gain - Variable from +6 to -90 dB. Default is 0 dB.
Defragment Disk - Eliminate fragmentation of audio files on disk.
Change Bank Name - Changes name of currently selected Bank.

The following are available only when EXTERNAL DRIVE is set to ENABLED:
Copy Cut – Copies a single Cut to or from the Internal Drive to the External Drive.
Copy Bank – Copies a Bank including the Cuts, Hot-Key Assignments and Playlist.
Copy Disk – Copies all Cuts to or from the Internal to the External Drive.

Configuration

Time Display - TIME REMAINING, ELAPSED TIME
Sort Directory By - INDEX, NAME
Select Language - ENGLISH, SPANISH
Digital Output - OFF, PROFESSIONAL FORMAT,

CONSUMER FORMAT, COPY PROT. CONSUMER

GPI Input- ENABLE, DISABLE
External Drive – DISABLED, ENABLED

Printer Output

Print - CURRENT BANK, ALL, LEGEND OVERLAY
Sort By - NAME, INDEX, HOTKEY #, PLAYLIST
Printer Type – CANON BJ200E, HP LASERJET

Note that Sort By only appears after the Print selections CURRENT, BANK or ALL have
been selected.

Playlist

Clear Playlist? - Press E

NTER

to clear Playlist stored within the current Bank.

Playlist Protection - OFF, ON

Hot-Keys

Assign Hot-Key - Scans list of Hot-Key Assignments in current Bank using S

CROLL

RROWS

. Pressing E

NTER

assigns current Cut (selected before the

ENU

key is pressed) to the displayed Hot-Key Assignment. This

is equivalent to using the A

SSIGN

-K

button.
