54

| SOL 25 PLUS

WWW.STIEBEL-ELTRON-USA.COM

Step 21: Install an M10 serrated flange nut.
Repeat this procedure for the other side.

Step 22: Align the bottom front ‘L’ brackets
as shown.

Step 23: Prepare to install the front left ‘L’
bracket. Note that the side of the ‘L’ bracket
with the hole closer to the edge is aligned
parallel to the support rails.
