Installation
13 AJ1031
Overall Dimensions and Connecting
Data
Figure 5
SCR97N
OPENO PE
N
CL
OSE
CL
O SE
CL
OSE
CL
O SE
STEAM INLET STEAM INLET
36-7/8 in.
(93.7 cm)
HEAD OPEN
38 in.
(96.5 cm)
1-1/2 in. TYP
(3.8 cm)
34 in.
(86.4 cm)
23 in.
(58.5 cm)
53 in.
(134.6 cm)
HEAD OPEN
HEIGHT
16 in.
(40.6 cm)
20 in.
(50.8 cm)
1 in. TYP
(2.5 cm)
2 in.
(5.1 cm)
