Installation
AJ1031 12
Dimensions and Specifications
Electrical Requirements
(Presses With Timers Only)
NOTE: Presses without timers do not require
electric hook-up.
115 Volt, 230 Volt/60 Hertz/1 Phase, (0.50, 0.25) full
load amps
110 Volt, 220 Volt/50 Hertz/1 Phase, (0.50, 0.25) full
load amps
Electrical Data
Laundry Press Net Weights Supply Requirements
Model
Weight Air
Steam (Max. Pressure
115 psig [7.9 bar])
lbs. kg
cu. ft. (cu. m)
free air/cycle
@ 80 psig
(5.5 bar)
BHP (kw)
@ 115 psig
(7.9 bar)
lbs. (kg)
conds/hr
LDCC 370 168 1 (.03) .75 (7.35) 26 (12)
LDBB 370 168 1 (.03) .75 (7.35) 26 (12)
Table 1
Nominal Voltage* 115 230 110 220
Frequency/Phase 60/1 60/1 50/1 50/1
Rated Amperes** 0.50 0.25 0.50 0.25
Average Running Amperes 0.31 0.16 0.31 0.16
Quantity Electrical Connections 2 + grd 2 + grd 2 + grd 2 + grd
* The voltages listed are rated machine voltages. The currents listed are rated for system voltage ranges of 110 – 220 and 220 – 240.
** Rated Amperes are to be used to determine incoming conductor size and short-circuit protection. Rated amperes are figured in
accordance with the 1981 NATIONAL ELECTRIC CODE, Sections 430-22 and 430-24.
Table 2
