Unit and Cassette Information
Erase Protection (Record Tab)
Cassettes have a record tab to ensure that
recordings are not accidentally erased.
To prevent accidental
erasure, break off the tab
with a screwdriver.
To record again, cover the
hole with cellophane tape.
Maximum Record/PlaybackTime
Only use tapes with the|VHSI >T^ark in this unit.
Tape Speed
Setting
Type of Video Cassette
T60 T120 T160
SP
(Standard Play)
1 Hour 2 Hours
2 Hours
40 minutes
LP
(Long Play)
2 Hours 4 Hours
5 Hours
20 minutes
SLP
(Super Long Play) 3 Hours
6 Hours 8 Hours
D.S.T. (Daylight Saving Time)
Spring (First Sunday in April)
When the Combination VCR is set to DST:ON, it
automatically adds one hour and adjusts the clock.
NCRMAL TIME
1:00 a.m. 2:00 a.m.
DAYLIGHT
SAVING TIME 3:00 a.m. 4:00 a.m.
Autumn (Last Sunday in October)
When the Combination VCR is set to DST:ON, it
automatically turns back one hour and adjusts the
clock.
DAYLIGHT
SAVING TIME
1:00 a.m. 2:00 a.m.
NORMAL TIME
1:00 a.m. 2:00 a.m.
SELF-DEMO MODE
In Power On condition, hold down PLAY/REPEAT
on the Combination VCR, with no tape inserted,
for 5 seconds. The demo screen appears.
To cancel: Repeat the above operation. The demo
screen disappears.
Reset all Combination VCR Memory Functions
Use when moving the Combination VCR to a new location, or if a
mistake was made in the One Time Setup section.
• Make sure a tape is not inserted in the Combination VCR.
1) Push POWER to turn the Combination VCR on.
2) Hold down both the PLAY and REWIND buttons on the
Combination VCR for more than 5 seconds.
• The power will shut off.
3) Turn the power back on and perform the One Time Setup
section on page 8 .
Head Cleaning
Your Combination VCR will not normally require head cleaning,
however the heads may become clogged when playing an old
or damaged tape.
VIDEO HEADS MAY
NEED CLEANING
PLEASE INSERT HEAD
CLEANING CASSETTE
OR REFER TO MANUAL
END:PLAY KEY
Head Clog Sensor
If head cleaning becomes necessary,
the Combination VCR will display the
screen at right while playing back a
recorded signal. To exit this screen,
push PLAY on the remote control or
Combination VCR.
• Use “dry” type head cleaning cassette* only.
• Be sure to follow the cleaning tape instructions carefully.
Excessive use of a cleaning cassette can shorten head life.
• If using a head cleaning cassette does not solve the
problem, contact your nearest Factory Service Center or
authorized Service Center. {See page 27.)
‘Cleaning cassette part No. NV-TCL30PT is recommended.
Product Specifications
Display
Picture Tube:
VCR
Video Recording System:
Audio Track:
Tuner:
Broadcast Channels:
CATV Channels:
20 inch measured diagonal 90“
deflection Picture Tube
2 rotary heads helical scanning system
1 track
VHF2-13, UHF 14-69
Midband A through I (14-22)
Superband J through W (23-36)
Hyperband AA-EEE (37-64)
Lowband A-5-A-1 (95-99)
Special CATV channel 5A (01)
Ultraband 65-94, 100-125
FM Radio
Band range:
87.5-108.1 MHz
General
o
Power Source: 120V AC, 60 Hz
Power Consumption: Approx. 110 watts (Power on)
(D
Approx. 6 watts (Power off)
Television System: EIA Standard NTSC color
3
Speaker: 1 piece
o
Cperating Temperature: 4rF-104“F (5“C-40“C)
3
fi)
Cperating Humidity: 10%~75%
Weight: 49.95 lbs. (22.67 Kg)
Dimensions: 20-3/10” (W) X 19-4/5” (H) X 19-1/10" (D) 5*
515 (W) X 503 (H) X 484 (D) mm
3
Note: Designs and specifications are subject to change without notice.
