Multi Button (For CT-2768S)
The MULTI button can be programmed to operate up
to 6 Remote function buttons at the same time.
For Example: TV Power/On, VCR Power/On (selected
brands) can be operated at the same time with one press
of the MULTI button.
Procedure
1. First program the Remote for the selected VCR
Infrared access code. Confirm that the Remote
Control is compatible with the equipment.
2. Face the Remote Control transmitter away from all
equipment remote sensors.
3. Press and hold down the Remote TV Power button,
then press and hold down the MULTI button at the
same time. Release buttons (All previous com­
mands will be erased.)
Special Functions (cont.)
POWER MULTI
4.
PRESS SIMULTANEOUSLY
Press a maximum of 6 Function buttons on the
Remote.
Each button you press is equal to one function. If six
Remote button functions are entered, all will register
in the MULTI button memory in the sequence
entered. When less than six Remote button
functions are entered, press the MULTI button to
end the program mode. (Waiting more than 30
seconds without pressing another button will also
end the program mode.)
The following is an example of Remote functions
that can be programmed into the MULTI button.
-
TV Power - For turning TV ON and OFF.
- VCR Power - For turning VCR ON and OFF
(selected brands after programming it’s Infrared
access code, if necessary).
Both can be turned ON or OFF with one press of the
MULTI button.
POWER VCR POWER
MULTI
To delete entered functions - Repeat step 3. Now
you can enter from one to six different Remote
functions.
NOTE: You can also program the MULTI button to
perform most individual Remote Control button
functions. Buttons which continuously perform a
function as long as pressed (Volume Up/Down,
Channel
Up/Down, etc.) cannot be
programmed. Only those buttons which perform
a function when initially pressed (Power On/Off,
Mute, Direct Channel Entry, etc.) can be
programmed.
Cable Power Button (For CT-2768S)
CABLE
POWER
The CZl on the Remote Control has been designed
to operate selected brands of Cable Television
Converter boxes. The proper cable television converter
box infrared code must be obtained prior to use. (Please
refer to Programming the Universal Remote for
programming instructions.) The Remote Control
TV/VCR/CABLE switch should be in the CABLE
position.
NOTE: The^ or ^ on the Remote may be used for
selecting Cable Converter box channels.
PIP (Picture in Picture) Button
This feature allows the viewer to monitor one channel
program while watching another. The monitored source
(PIP) must be a different video source (such as a VCR)
when connected to the input jacks.
• S-Video connection will also operate the PIP feature
(refer to OPTIONAL S-VIDEO VHS CONNECTION
section).
• When the Main Picture is in Video mode with no
signal, the PIP will not operate properly.
PIP Operation
1. Turn VCR ON and select a desired channel.
Press the TV Mode Selection button to operate TV
Remote functions, if necessary (some models).
Press the PIP button (set must be ON). The PIP
frame will appear at the position it was last
displayed. The Main Picture Video Source and PIP
Video Source will display on screen momentarily.
Audio will be that of Main Picture.
2 .
3.
Main
with
Audio
Main Picture
Channel
Picture in
Video Source
Picture in
Frame
4. Press the PIP button again to cancel PICTURE IN
PICTURE feature (if desired).
Note: For PIP Video source connection, refer to the
PIP External Video and Antenna Connections
section.
- 1 7 -
