Specifications
I Power Source
220 - 240 V AC, 50/60 Hz
Power Consumption
TC-42P1F
Normal use: 380 W
Stand-by condition: 1.7 W
Power off condition: 0.7 W
TC-37P1F
Normal use: 290 W
Stand-by condition: 1.7 W
Power off condition: 0.7 W
Plasma Display panel
TC-42P1F TC-37P1F
Drive method AC type Drive method AC type
42-inch, 16:9 aspect ratio 37-inch, 16:9 aspect ratio
Screen size
TC-42P1F TC-37P1F
920 mm (W) x 518 mm (H) x 1056 mm (diagonal) 818 mm (W) x 461 mm (H) x 939 mm (diagonal)
No. of pixels No. of pixels
408,960 (852 (W) x 480 (H)) [2,556 x 480 dots] 408,960 (852 (W) x 480 (H)) [2,556 x 480 dots]
Operating conditions
Temperature: 0°- 40°C
Humidity: 20% - 80%
1 Appiicable signais
Colour System: NTSC, PAL, PAL-60, SECAM (Modified NTSC signals cannot be displayed.)
Scanning format: 525i, 525p, 625i, 625p, 1080i
PC signais: VGA, S-VGA (compressed), Horizontal scanning frequency 15.6 - 50 kHz
Connection terminais
AV VIDEO IN (BNC) 1.0 Vp-p (75 n)
(with 75 Q. or high-impedance auto select)
S-VIDEO IN (Mini DIN 4-pin) Y: 1 Vp-p (75 a),C: 0.286 Vp-p (75 U)
AUDIO IN L-R (RCA pin jack x 2) 0.5 Vrms
VIDEO OUT (BNC)
1.0 Vp-p (75 Q) (bridge output)
COMPONENT/RGB Y/G 1.0 Vp-p (including synchronisation)
P b /B ± 0.35 Vp-p
P r /R ± 0.35 Vp-p
HD ±1.0-5.0 Vp-p
VD ± 1.0-5.0 Vp-p
AUDIO IN L-R (RCA pin jack x2) 0.5 Vrms
PC VIDEO (High-density D-sub 15-pin)
AUDIO
0.5 Vrms (3 mm mini jack)
SPEAKERS (8 0) For TY-SP42P1E only. (For TC-42P1F)
For TY-SP37P1E only. (For TC-37P1F)
SERIAL
TUNER
REMOTE
External control terminal
