CONTENTS
PREFACE .............................................................................................................................................................................................. 2
FEATURES ........................................................................................................................................................................................... 2
PRECAUTIONS ..................................................................................................................................................................................... 2
SYSTEM BLOCK DIAGRAM ................................................................................................................................................................. 3
MAJOR OPERATING CONTROLS AND THEIR FUNCTIONS ............................................................................................................ 3
PREPARATIONS ...................................................................................................................................................................................5
CONNECTIONS .................................................................................................................................................................................... 6
GEN-LOCK ADJUSTMENTS ................................................................................................................................................................ 7
INSTALLATIONS ................................................................................................................................................................................... 7
SPECIFICATIONS ................................................................................................................................................................................. 8
STANDARD CONFIGURATION ............................................................................................................................................................ 8
OPTIONAL ACCESSORIES ..................................................................................................................................................................8
C A U T I O N
RISK OF ELECTRIC SHOCK
DO NOT OPEN
SA 1966
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR BACK). NO USER SER­
VICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
The lightning flash with arrowhead
symbol, within an equilateral triangle,
is intended to alert the user to the
presence of uninsulated "dangerous
voltage"
within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of elec­
tric shock to persons.
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the literature accompa­
nying the appliance.
SA 1965
.................................................................................................For U.S.A
Warning:
This equipment generates and uses radio frequency
energy and if not installed and used properly, i.e., in
strict accordance with the instruction manual, may
cause harmful interference to radio communications.
It has been tested and found to comply with the limits
for a Class A computing device pursuant to Subpart
J of Part 1 5 of FCC Rules, which are designed to pro­
vide reasonable protection against such interference
when operated in a commercial environment.
.......................................................................................... For CANADA
This digital apparatus does not exceed the Class A
limits for radio noise emissions from digital apparatus
set out in the Radio Interference Regulations of the
Canadian Department of Communications.
The serial number of this product may be found on
the bottom of the unit.
You should note the serial number of this unit in the
space provided and retain this book as a permanent
record of your purchase ,to aid identification in the
event of theft.
Model No.
Serial No. .
GP-MS112
WARNING:
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
- 1 -
