Installing the SmartSwitch 9000 Module

Figure 2-1. User-Accessible Components

SMB-1

PROM

Flash SIMM

Socket

32 MB
DRAM

i960
Processor

DIP Switch

Boot
PROM

1
2
3
4
5
6
7
8

HSIM

Connector

VHSIM
Connector
