Specifications
Item Description
Power Supply Input DC 15.1 V [ Do not use other than the speci-
fied AC adapter (Model No.: CF-AA1527)j.
Expansion Bus Connector 100-pin female
Parallel Port Dsub 25-pin female
Display port Mini Dsub 15-pin female
Serial Port Dsub 9-pin male
Microphone Jack Miniature jack, 3.5 DIA
(Use only a monaural condenser microphone ,)
Headphone Jack Miniature jack, 3.5 DIA
Keyboard Port Mini DIN 6-pin female
Mouse Port Mini DIN 6-pin female
USB Port 4-pin
FDD Port 26-pin female
For External Floppy Disk Drive(CF-VFDUOl)
Physical Dimensions
(Width
X Depth x Height)
229 mm x 138 mm x 76 mm
{9.02” X 5.43” X 2.99"}
Weight Approx. 0.85 kg {1.87 lb.}
Operating Environment
Temperature / Humidity 5
°C
to 35 “C {41 °Fto 95 °F}/
30 % RH to 80 % RH (no condensation)
1 0
