Page 33, Professional studio amplifiers – Crown Audio STUDIO AMPLIFIER User Manual
Page 33
Page 33
Studio Reference
IIIII & II
II
II
II
II
Professional Studio Amplifiers
10
100
1 K
10 K
100 K
FREQUENCY (Hz)
+2
+1
0
–1
–2
–3
–4
dB
–5
–6
–7
4 ohm
8 ohm
1 watt
DAMPING
20
100
1 K
10 K
20 K
100
10
1,000
10,000
100,000
OHMS
0.001
0.0001
0.01
0.1
1
FREQUENCY (Hz)
8 ohm
20
100
1 K
10 K
20 K
FREQUENCY (Hz)
8 ohm
Fig. 6.5 Typical Frequency Response
Fig. 6.6 Typical Damping Factor
Fig. 6.7 Typical Output Impedance
