141. Tally Indicator (REC/TALLY)
When the Remote Control Box (RGB) is used in
conjuction with a Special Effects Generator, the
Tally Indicator inside the viewfinder as well as this
indicator on the Remote Control Box (RGB) will tight
to indicate that recording is in progress.
Note:
When using the Remote Control Box (RGB) in
the Remote Control Unit (RCU), the recording
start/stop function is not available.
154, Monitor Output Connector
As this connector is in parallel connection with
the VIDEO 2 OUTPUT Connector on the RCU,
do not output the signal simultaneously from both
connectors.
155. Gen-lock Input Connector of Remote Control
Box
This connector is used to Input the gen-lock signal
to this control box when using the Remote Control
Box extended from the Remote Control Unit.
156. Remote Control Unit Extension Connector
This connector is used to extend this control
box from the Remote Control Unit or from
the camera by using the optional RGB cable
(WV-CA10825/WV-CA10B50).
The maximum cable length for the extension is 300 ft
(100m),
Refer to the following table.
Cable length (ft) 6 75 150 300
(m) 2 25 50 100
Decrement 10'/. ^ 5'/. 207. 307.
Note:
As the video level is changed by using various
cable lengths, under certain conditions it may
be out of the specification for the WV-F700 or
WV-F500 series.
167. Remote Control Unit Connector
This connector is used for directly connecting with
the Remote Control Box Connector on the Remote
Control Unit
- 9 -
