Optional Equipment Connection and Operation
To Audio AMP Connection (Stereo)
Connect to an external audio amp auxiliary input for monitoring sound through a stereo system.
TERMINALS ON BACK OF RECEIVER
‘TO
AUDIO
AMP”
terminals
cannot be used directly with
external speakers.
(Not Supplied)
Adjustment - When an audio amp is connected to ‘TO AUDIO AMP” terminals:
1. Select TV SPEAKERS “ON ” Mode. (Refer to the Audio Menu TV Speakers section.)
Set volume of audio amp to near minimum.
Adjust volume of TV to desired listening level.
Adjust volume of audio amp to match the level of TV.
Select TV SPEAKERS “OFF&VAO ” Mode. (Refer to the Audio Menu TV Speakers section.)
Audio bass, treble, balance, volume and mute can now be controlled by the TV Remote Control.
NOTE: When Selecting TV SPEAKERS “OFF&FAO” Mode, the TV sound output is always at a constant level and cannot
be changed (Refer to the Audio Menu TV Speakers section).
AudioA/ideo Input Connection
TERMINALS ON BACK OF RECEIVER
S-Video connection is optional
and overrides the standard Video
connection when connected.
§m
OPTIONAL EQUIPMENT
«il
Ww I
I: ^—Li
mp
Ô
:Q nm
TERMINALS ON BACK
OF EQUIPMENT
Operation
1. Connect optional equipment as shown to INPUT 1 or 2 terminals. If S-Video is to be used, connect S-Video (YC)
connector to S-Video termina! and connect audio cables to L & R Audio INPUT 1 terminals.
2. Select the desired Video mode by pressing the TVA/IDEO button.
3. Operate optional equipment (VCR-VDP) as instructed in Optional Equipment manual.
NOTE:
• You must select the same VIDEO Mode that the equipment is connected to.
• Connection of optional S-VIDEO jack automatically disconnects the Normal Video Input 1 jack.
-
7
-
