Technical Reference Manual

V1.20

10/12
725538.doc

08.11.01

DISTO

OEM module 3.0 WH15/WH30

6.2.7. Tracking

(H)

Function:

Triggers continuous measurement of distance. The measurements are continued until the next
command is issued or until a fault arises.

GSI IN:

GSI OUT:

WI31

or @Exxx

6.2.8.

Signal measurement (k)

Function:

Triggers continuous measurement of the signal. The measurements are continued until the
next command is received or until a fault arises.

GSI IN:

GSI OUT:

WI53

or @Exxx

6.2.9.

Temperature measurement (t)

Function: :

Triggers measurement of temperature.

GSI IN:

GSI OUT:

WI40

or @Exxx

6.2.10.

Laser (o, p)

Function:

Switches laser on or off.

GSI IN:

Switches laser on

Switches laser off

GSI OUT:

or @Exxx

6.2.11.

Software version (00)

Function:

Outputs software version at interface.

GSI IN:

N00N

GSI OUT:

WI13

or @Exxx

6.2.12.

Hardware version (01)

Function:

Outputs instrument type at interface.

GSI IN:

N01N

GSI OUT:

WI14

or @Exxx

6.2.13.

Serial number (02)

Function:

Outputs serial number at interface.

GSI IN:

N02N

GSI OUT:

WI12

or @Exxx

6.2.14.

Date of manufacture (03)

Function:

Date of manufacture at interface.

GSI IN:

N03N

GSI OUT:

WI15

or @Exxx

6.2.15.

Setting distance offset (44)

Function:

Sets distance offset. The offset is added to each distance measured. Setting is nonvolatile!

GSI IN:

N44N%N
%: Distance offset [1/10mm] within the range ±29.999m

GSI OUT:

WI58

or @Exxx
