13 Laser Locator-1.0 en
Combined measurement with data transfer (distance, azimuth, inclination)
i
Distance measurements
Measurement data is transmitted
via the (optional) interface cable
immediately after the
measurement is taken (see
page 22).
It is not possible to store
measurement data in the Laser
Locator itself. Hold down both keys simultane-
ously; the pointing circle appears,
together with the current azimuth.
Sight the object with the pointing
circle.
Release both keys while holding
the Laser Locator steady.
The azimuth appears at the left
and the distance at the right of
the field of view.
The inclination angle is not
displayed, but it is sent via the
data interface.
Setting measurement units:
see page 26.
