12 Laser Locator-1.0 en
Multiple object measurement
i
Distance measurements
Up to 3 separate distances can
be obtained with a single
measurement, for example
when:
- the laser beam passes through
objects in front of the main
target (bushes, shrubs, etc.)
- there are reflective objects
behind the main target
(mountains, etc.)
The distance display blinks for a
few seconds after a multiple
distance measurement. Click the
distance key repeatedly to
obtain all the measured
distances in succession. To use this feature, ”3diS on”
(3 distances) must be
activated via the configuration
menu; see page 25.
Sight on the most visible portion
of the object. Operate the Laser
Locator as described under
”distance measurement”.
