PARTS LIST
S39NT
This list contains replaceable parts used in your heater. When
ordering parts, follow the instructions listed under Replacement
Parts on page 24 of this manual.
KEY
NO.
PART NO.
DESCRIPTION
QTY.
1
107085-01CK
Top Panel, Stove
1
2
**
Pedestal Stove Assembly
1
3
107076-01CK
Stove Base
1
4
**
Stove Back Panel
1
5
107082-01CK
Top Trim
1
6
105657-01
Blower Bracket
2
7
107363-01CK
Door
1
8
107078-01CJ
Firebox Back Panel
1
9
107080-01CK
Firebox Floor
1
10
107081-01CJ
Firebox Top
1
11
107365-01CK
Screen Assembly
1
12
101382-01
Valve Bracket
1
13
107092-01
Brass Trim, Bottom
1
14
107093-01
Brass Trim, Firebox
1
15
106754-01
Knob
1
16
101386-02
Door Hinge
2
17
099230-02
Shoulder Screw
4
18
107079-01CJ
Heat Deflector
1
19
102455-12
Louver, Small
2
20
102455-13
Louver, Large
1
21
107091-01CK
Support, End Louver
2
22
107084-01CK
Support, Center Louver
2
23
101514-01
Blower Sensor Cover
1
24
103158-01
Magnet Catch
1
25
107083-01
Magnet Bracket
1
26
098304-03
Louver Screw
12
PARTS AVAILABLE — NOT SHOWN
101054-01
Lighting Instructions Plate
1
100563-01
Warning Plate
1
104108-06
Touch-Up Paint Kit
1
PARTS LIST
S39NT Stove Body
** Part not available for field replacement.
