Leica Geosystems Leica DISTO Classic5 - Manual (Page 8)

8 Functions DISTO classic 5 1.2.0 en
de
en
fr
it
es
pt
nl
da
sv
no
fi
jp
zh
ko
pl
hr
hu
ru
cz
el
Tracking - Minimum
D5-Z11
Determine the minimum dimension, e.g. ceiling height,
without having to precisely align to the normal.
Press until
appears on the display.
Aim DISTO approximately at the target point.
Activate continuos measurement with a brief
press.
Move the DISTO a large amount around the target point.
Stop continuous measurement.
The smallest measurement is displayed (e.g. 3.215m =
height of room).
)
Both planes (e.g. floor/ ceiling, walls) must be
nearly parallel to each other.
Tracking - Maximum
D5-Z12
Determine maximum dimension, e.g. to determine the
(room) diagonal.
Press until
appears on the display.
Move the DISTO a large amount around the target point.
Activate continuous measurement with a brief
press.
Slowly rotate the DISTO to the right/ left past the corner.
Stop continuous measurement.
The largest measurement is displayed (e.g. 12.314m =
diagonal of room).
Calculations
Partial heights, partial distances
Make measurement.
Add by [ + ] key/ Subtract by[ - ] key.
Make additional measurements.
= Result.
)
In the same way chain values (= any amount of
distance measurements) and sums of areas/ volumes can
be added up.
)
During calculations "Clear" is available as long
as the function has not been executed!
