Leica Geosystems Leica DISTO Classic5 - Manual (Page 11)

11 User Information
DISTO classic
5
1.2.0 en
de
en
fr
it
es
pt
nl
da
sv
no
fi
jp
zh
ko
pl
hr
hu
ru
cz
el
Determination of a partial height with 3
points
Height determination between
point 1 and point 2 with three
measured points.
Press until
appears on the display; laser is activated and
"1 ---" starts blinking.
Aim at the upper point (1).
Trigger measurement; do not move the
instrument!
Value is accepted and on the display "2 ---" starts blinking.
Trigger measurement; do not move the
instrument!
Value is accepted.
appears on the display and "3 ---" starts blinking.
Press, a continuous measurement is triggered.
Move the DISTO a large amount around the ideal
measurement point.
Stop of continuous measurement. The height
and width are displayed between point 1 and 2
(Pythagoras).
User Information
Range
In daylight (outdoors) always work with laser viewfinder. If
neceesary, shade the target.
Increased range:
At night, at dusk and when target area is in the shade.
Reduced range:
By mat green and blue surfaces (also by plants or trees).
Rough surfaces
On a rough surface (e.g. coarse plaster) measure against
the centre of the illuminated area.
To avoid measuring to the bottom of plaster joints:
Use target plate, 3M "Post-it" or board.
Transparent surfaces
To avoid measuring errors, do not measure towards
colorless liquids (like water) or (dust free) glass.
For materials and liquids unfamiliar to you always take a
trial measurement.
