18 Technical Data DISTO classic 5 1.2.0 en
de
en
fr
it
es
pt
nl
da
sv
no
fi
jp
zh
ko
pl
hr
hu
ru
cz
el
Technical Data
All rights reserved to make technical changes.
*
Display unit as off 100m : 1 cm
** At long range ± 5 ppm (± 0,5mm/ 100 m) plus short
range error.
Message Codes
Error message
appears beside the message number on the
display.
In case of this message switch on/off instrument
several times and check if message is still
displayed. Then call service and specify the
message displayed.
Care
Look after the optical surfaces with the same care that you
would apply to spectacles, cameras and field glasses.
Measuring accuracy
(2x standard deviation)
typ.: ± 3mm / max.: ± 5mm
Smallest unit displayed 1mm
Range 0.2m up to 200 m * **
Time for a measurement dist / trc 0.5...ca.4s / 0.16...ca.1s
∅ Laser spot (at distance) 6 / 30 / 60 mm (10 / 50 / 100 m)
Integrated telescopic viewfinder
Illumination
Multiline display
Multifunctional bumper
Time delay release
Pocket calculator
Tracking
Constant 10 values
min./ max. Tracking.
Pythagoras
Mermory (Stack) 15 Werte
Battery, Type AA, 2x 1.5V up to 10’000 measurements
(only with Alkaline batteries!)
Splash and dust
proof
IP54 acc. IEC529: splash proof,
dust proof
Dimension and weight 172 x 73 x 45 mm, 335g
Measuring accuracy of bubble 1°
Temperature range
Storage
Operating
-25°C to +70°C
(-13°F to +158°F)
-10°C to +50°C
(-14°F to +122°F)
Message
Code
Cause Remedy
203 Wrong sequence with
Pythagoras meas.
Carry out measurement in
correct sequence
204 Calculation error Repeat procedure
252 Temperature too high,
above 50°C (measuring)
Cool down instrument
253 Temperature too low,
below -10°C (measuring)
Warm up instrument
255 Receiver signal too weak,
measurement time too
long, distance <200 mm
Use target plate
measurement time >10
sec.
256 Received signal too
powerful
Use target plate (correct
side)
257 Wrong measurement,
ambient brightness too
high
Use target plate
260 Laser beam interrupted Repeat measurement
All other messages Call service "System"
Message
Code
Cause Remedy
