Appendix E: Encoder Serial-to-Gray Code Converter Installation
INTRODUCTION AND DESCRIPTION
The Encoder Converter is an electronic device that receives the serial encoder data from the
EFIS-D100 and outputs standard Mode-C parallel Gray code into your Mode-C transponder.
This Encoder Converter requires data from the EFIS-D100 and is not to be confused with other
ay be
ate with Gray code transponder
ribes the wiring requirements for using the Encoder Converter. Please
xplicitly as improper wiring can result in permanent damage to your
RACTICES
el wire,
ponder.
nual
wire sh
ne
end of the Encoder Converter in a single bundle. If your transponder has a switched power
standalone encoders available on the market. While the installation is not complex, it is
important that you install the unit correctly. The Encoder Converter does not output an encoder
strobe signal.
The Encoder Converter is designed to be powered off voltages between 10 and 30 volts.
TOOLS AND EQUIPMENT
The following parts are not included with your Encoder Converter purchase but m
necessary to complete the installation.
Wire cutters
Connector crimp tool
Crimp pins
25-pin EFIS harness to mate with EFIS-D100 (may have been purchased with your EFIS-
D100)
Connector to m
ELECTRICAL INSTALLATION
The following section desc
follow these instructions e
unit.
RECOMMENDED WIRING P
NOTE: Use correct splicing techniques for all electrical connections, taking care to properly
insulate any exposed wire. A short circuit between any of the wires may cause damage to the
Encoder.
The wire used in construction of your Encoder Converter is 22 gauge avionics grade Tefz
which meets Mil Standard MIL-W-22759/16.
Installing: Make sure all connections are secure and all wires are routed and strain relieved to
ensure that the wires will not chafe against any other object in the aircraft.
STEP 1: TRANSPONDER WIRING
Wire the Encoder Converter signals to their respective connections on your Mode-C trans
Mode-C transponder pin-outs vary from device to device. To find the correct pin-out, look at the
ma
for your transponder or contact its manufacturer. The table below details which color
ould be connected to each Transponder pin. All of the wires listed in the table leave o
