9160 10 Gigabit Ethernet Network Interface Device

5-1

Chapter 5

Specifications

9161 Specifications

Standards: IEEE

802.3

Dimensions:

1.72" H x 13.375" W x 17.25" D (44 x 340 x 438 mm)

Weight:

0.3 lb. (0.136 Kg)

Operating Temperature:

0° to 50° C

Operating Humidity:

Up to 90% (non-condensing)

Power Consumption:

5 VDC 800 mA Maximum

Optical Connectors:

ST or SC

Regulatory Compliance

• ETL, cETL & LVD (UL 60950 CAN/CSA C22.2 No. 60950, EN/IEC 60950)
• EMC Directive (EN55022 Class A, EN 55024, EN 61000-3-2/-3-3)
• CE Mark
• FCC Part 15B (U.S.)/ICES-003 (CAN)
• VCCI Class A (Japan)
• C-Tick (AS/NZS 3548 - Australia)
• CDRH CFR21/IEC 60825-1 (Laser Safety)
• NEBS Level 3 Certified & Tested

EIA-232 Pinout

Pin Number

Signal Name

Source

I/O

1 DCD

DCE

Output

2 TxD

DCE

Output

3 RxD

DCE

Input

4 DTE

DCE

Input

5 SIG

GND

6 DCE

DCE

Output

7 CTS

DCE

Input

8 RTS

DCE

Output

9 RI

Not

Used
